Product Name : Auxiliary Instrument Panel
Resin : PP+GF30%
Weight : 1200g
System Type : TINA AM
Cavity : 1
Description ：
1.The injection part is in complex structure with heavy weight and long flow path, thus the injection molding solution is four drops valve system with sequence control to avoid welding lines.
2. The maximum TINA AM 22 hot runner system is applied to achieve big injection volume, thus to ensure stable filling and reduce pressure drop.
3. As the resin contains glass fiber, the hot runner tip is made from special material in special structure to ensure the temperature in gate area and service life of nozzle head.
